Model |
HTC-3540-PS |
|
Type |
HTC-series medium/heavy duty-package size, flanged base |
|
Base type |
Flanged |
|
Material |
Steel |
|
Finish |
Zinc plated/black powder coated |
|
Plunger travel |
40.00mm |
|
Handle opening |
183degree |
|
Holding capacity X1 |
3.90KN |
|
Width |
61.00mm |
|
Height |
117.00mm |
|
Weight |
1.50Kg |
The straigh line action toggle clamp design uses a straight line or push/pull toogle clamping action. the push pull handle is easy to operate s move the plunger of the clamp in and out along its axis most of these clamps cum be locked in two positions allowing you to use them as either push or pull clamps. the clamp are manufactured in a variety of modelsa to accommodate a wide range of load rating ( 45Kg- 4500Kg )
