Mitutoyo Interchangeable Thread Micrometer 126

Mitutoyo Interchangeable Thread Micrometer 126

Price :
₹ 12412.00
GST inclusive
Code:
Quantity:
Add to Cart

Order No.

Range

Graduation

Spindle feed error

126-125

0-25mm

0.01mm

3µm



  • Use by installing a suitable interchangeable anvil/spindle tip pair.
  • Direct reading of screw pitch diameter ( no need for calculation)
  • Equipped with ratchet stop for constant measuring force.
  • Supplied with a setting standard for adjusting zero point for metric (unified) 60degree threads
  • Interchangeable anvils/spindle tips are optional.
  • This screw thread micrometer should be used with optional, interchangeable anvils/ spindle-tips that allow you to measure a wide range of metric/unified and whitworth screw-thread pitch diameters. A metric (unified) 60degree standard in included with all models except those measuring from 0. to measure metric/unified or whitworth threads, anvils and spindle points are interchangeable in matched pairs. measurement of screw pitch diameter directly ( no need for calculation ) included a ratchet stop for accurate force measurement interchangeable anvils or spindle tips are available as an option.
