Mitutoyo Disk Micrometer Series 123

Mitutoyo Disk Micrometer Series 123

Price :
₹ 1076.00
GST inclusive
Code:
Quantity:
Add to Cart

Order no

Range

Graduation

Maximum permissible

Error JMPE

Anvil dia

Measurable

module

123-106

125-150mm

0.01mm

±7µm

Ø30mm

0.7-11

123-105

100-125mm

0.01mm

±7µm

Ø30mm

0.7-11



  • Measure "root tangent length" of spur geara and helical gears.
  • Determination of the root tangent length: refer to "quick guide to precision measuring instrument"
  • Equipped with ratchet stop for constant measuring force.
  • Supplied with a setting standard (except for 0 to 25mm/0 to 1in measuring range)
