Mitutoyo Digimatic Indicator ID-SX Series

Mitutoyo Digimatic Indicator ID-SX Series

Price :
₹ 7234.00
GST inclusive
Code:
Quantity:
Add to Cart

Order.No

Range

resolution

Overall*

Hysteresis

Repeatability

Back type

Measuring Force

Battery life

(continous use )

Dust/water protection level

543-781

0-12.7mm

0.01mm

0.02mm

0.02mm

0.01mm

flat

1.5N or less

20.000Hours

IP42



  • Cost-effective oriented design ID-SX indicators use a button-type battery (SR44) and come with the minimum of functionality for ease of use. There is a choice of models in the lineup allowing selection of 0.01 mm, 0.001 mm or inch-based measurement resolutions.
  • IP53 dust/water protection level The models listed below also provide IP53 dust/ water protection level specifications: 543-794/94B/95/95B/96/96B
  • These Digimatic indicators employ Mitutoyo’s proprietary ABS (absolute) scale, which makes it possible to restore the origin point even if the power is turned off. This eliminates the need to perform origin restoration each time the power is turned on. Furthermore, this scale ensures that overspeed errors do not occur, which improves reliability.
  • Equipped with a data output port that enables incorporation into measurement networking and statistical process control systems.
