Mitutoyo Digimatic Indicator 543-390

Mitutoyo Digimatic Indicator 543-390

Price :
₹ 17788.00
GST inclusive
Code:
Quantity:
Add to Cart

Order no

Range

Resolution

Maximum permissible error*

Measuring force

MPL(M)

MPE

Hysteresis MPEH

Repeatability MPER

543-390

12.7mm

0.001/0.01

selectable

0.003

0.002

0.002

1.5 or less



  • The ABS (absolute) scale restores the last origin position automatically when the indicator is turned on.
  • Mitutoyo's absolute linear encoder, reliability has been increased due to elimination of over-speed errors.
  • Tolerance judgment can be performed by setting upper and lower tolerance limits. the judgment result (GO-NO-GO) can be displayed in full-size charactors.
  • Battery life of approx. 7,000 hours in continouus use has been achieved with only one battery.
  • Equipped with a data output part that enables incorporation into measurement networking and statistical process control system.
