Price :

₹ 12445.00

GST inclusive

Code:

Quantity:

Add to Cart

Order no	Range	Resolution	Maximum permissible error JMPE	Parallelism	Constant-force device	Mass (g)
293-230	0-25mm	0.001mm	±1µm	1µm	With ratchet stop	270
293-231	25-50mm	0.001mm	±1 µm	1 µm	With ratchet stop	330
293-240	0-25mm	0.001mm	±1 µm	1 µm	With ratchet stop	270
293-241	25-50mm	0.001mm	±1 µm	1 µm	With ratchet stop	330
293-242	50-75mm	0.001mm	±1 µm	2 µm	With ratchet stop	470
293-243	75-100mm	0.001mm	±2 µm	2 µm	With ratchet stop	625
293-250	100-125mm	0.001mm	±2 µm	3 µm	With ratchet stop	740
293-252	150-175mm	0.01mm	±3 µm	3 µm	With ratchet stop	800
293-345	1-2in	0.00005in/ 0.001mm	±0.00005	0.00004	With ratchet thimble	340

World's highest performing micrometer overall.
Extended battery life of approximately 2.4 years.
Ergonomic anti-slip frame cover and front panel for more comfortable hand-held measurements.
Ratchet thimble provides better operability for one-handed operation.
Oil-resistant material used for all plastic parts.
Models equipped with a Digimatic output port can form part of a statistical process control or networked measurement system. (Refer to page A-3 for details.) Interface Input Tools are available that enable the conversion of measurement data to keyboard signals that are then directly input to cells in off-the-shelf spreadsheet software such as Excel. (Refer to page A-13 for details.)
Two types of constant-force devices are available: Ratchet Stop and Ratchet Thimble. • Measuring faces: Carbide.

Mitutoyo Coolant Proof Micrometer Series 293
