Lubrite Lubricating Pump LAU-05FPS

Lubrite Lubricating Pump LAU-05FPS

Price :
₹ 12630.00
GST inclusive
Model:
Quantity:
Add to Cart

Model

LAU-05FPS

Reservoir capcity

5LTS

Discharge of pump

1LPM

Motor

3Ø, 0.18Kw, 415W

Relife value setting

20Kg, cm²

Pressure switch setting

15kg, cm²

Float switch

220v, 1AMP Max



  • Motorised Lubrication units are electric motor driven pumps along with reservoir, oil filter & breather, suction strainer, pressure relief valve & bleed valve etc. The units installed are suitable for Single Shot Automatic Oil Lubrication. These motorised Lubrication Units are to be run intermittently only.
  • During Motors ON time (Normally 5 seconds) all the metering cartridges eject out predetermined amount of oil at various points of the machine. And during motors OFF period (selectable) the metering cartridges get recharged for the the next Lubrication Cycle.
  • If desired, these units can be supplied without float & pressure switch as per customer requirements. Units for liquid grease (fluid grease) are also manufactured.
