PRODUCT DETAILS | TOOLBABA

Price :

₹ 25340.00

GST inclusive

Quantity:

Add to Cart

Code	HDT-L411
Resolution	1HLD, 1HV, 1HB, 0.1HRC, 0.1HRB, 0.1HRA, 0.1HS, 1SGM
Accuracy	±6HLD (when HLD=800)
Output	USB
Measuring range	HL100-960, HRC1-74.7, HRB1.2-140, HB28-1027,HV45-1230 HS4-112, HRA7-88.5, SGM(rm)118-3315N/mm²
Applicable workpiece	Minimum weight	5Kg (direct measurement)
		2Kg (on solid support)
		0.05Kg (coupled on plate)
	Minimum thickness: 5mm
	Minimum radius of curved surface: 30mm
	Maximum roughness (Ra): 2µm
Power supply	1x AAA battery
Dimension	148x45x21mm
Weight	105g

Impact device D
Universal testing angle, no need to set impact direction
Dual-coil probe, high accuracy
Based on leed (HLD), converted to vickers (HV), Brinell (HB), rockwell (HRC, HRA and HRB), shore (HS) and tensile strength (SGM)
Dual value display, shows both leed and converted hardness
High contrast digital LCD display
Can choose large fort display
Automatically calculate maximum, minimum, average value
Connected to PC via USB
Save 999 data
Operating temperature: -20ºC~45ºC
According to ASTM A956, DIN 50156, GB/T 17394

Insize Portable Leeb Hardness Tester (Basic Type) HDT
