IMI Quick Change Tapping Chuck QCLK/TPI-80

IMI Quick Change Tapping Chuck QCLK/TPI-80

Price :
22305.00
GST inclusive
Model:
Quantity:

Model

For taps

Suitable adaptor size

Length Compensation

ØD

ØD1

Ordering number & L Taper ISO-26623 PTI-80

Comp.

EXP.

QCLK1

M3-M12

1

7.50

7.50

36

19

20,171,700, L-110.00

QCLK2

M8-M20

2

12.50

12.50

53

31

20,172,700, L-145.00

QCLK3

M14-M33

3

20.00

20.00

78

48

20,173,700, L-160.00



  • For use on CNC machining center, CNC turning center, center lathe, drilling machine, length compensation acting on compression and exparsion to compensate for difference between spindle feed and pitch of thread. the chuck is equipped with pressure point mechanism to increase the cutting pressure to ensure positive start when tapping cycle emmences.
