IMI Quick Change Tapping Chuck QCLK/HSK100

IMI Quick Change Tapping Chuck QCLK/HSK100

Price :
₹ 20445.00
GST inclusive
Model:
Quantity:
Add to Cart

Model

For Taps

Suitable adaptors size

Length compensation

ØD

ØD1

Ordering number & L Taper DIN 69893 A HSK100

Comp.

Exp

QCLK1

M3-M12

1

7.50

7.50

36

19

26,161,060, L-112.50

QCLK2

M8-M20

2

12.50

12.50

53

31

26,162,060, L-148.50

QCLK3

M14-M33

3

20.00

20.00

78

48

26,163,060, L-215.00



  • For use on CNC machining center, CNC turning center, center lathe, drilling machine, length compensation acting on compression and exparsion to compensate for difference between spindle feed and pitch of thread. the chuck is equipped with pressure point mechanism to increase the cutting pressure to ensure positive start when tapping cycle emmences.
